6B Series Six Cylinder Water Cooled Diesel Engine Assy 6BTA5.9-
C180 For Construction Machine
Products Advantage:
1. exceptional performance, low weight, low operating costs, and
the reliability and durability expected
2. advanced thermal engineering, electronic integration, and a High
Pressure Common Rail fuel system
3. Lower emissions levels beyond Euro IV can be achieved without
sacrificing performance and with minimal impact on installation.
Products Details:
| Engine Model: | 6BTA5.9-C180 |
| Engine Type: | 6 Cylinders in Line |
| Displacement: | 5.9 L |
| Rated Speed: | 2200 rpm |
| Rated Power: | 132 kW(180 HP) |
| Max. Torque/Speed: | 750 N.m @1300 rpm |
| Aspiration Method: | Tcharged & Intercooled |
| Emission Standard: | Euro I |
| Fuel Consumption: | 227 g/kW.h |
| Packing Size(L*W*H): | 1300*900*1400 |
| Gross Weight: | 500 Kg |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T ,L/C |
| General Information of 6BTA5.9-C180 Construction Diesel Engine |
| Engine Model | 6BTA5.9-C180 |
| Engine Type | 6 Cylinders in Line |
| Displacement | 5.9 L |
| Bore*Stroke(mm) | 102 * 120 |
| Engine Configuration Number | D403039CX02 |
| Net Weight (with flywleel & alternator) | 453 Kg |
| Overall Diemension(L*W*H) | 1110mm*750mm*988mm |
| |
| Technical Specification of 6BTA5.9-C180 Construction Diesel Engine |
| Certification | Euro I |
| Aspiration | Turbocharged & Intercooled |
| Fuel System | Wuxi Weifu A Pump/RSV Governor |
| Electrical System(Starter Motor/Alternator) | 12V/24V |
| Lowest Starting Temp without auxiliary system | 0℃ |
| Engine Cooling Fluid Volume | 10.4 L |
| Performance Data of 6BTA5.9-C180 Construction Diesel Engine |
| Rated Power/Speed | 132 kW/180HP @ 2200rpm |
| Max.Torque/Speed | 750 N.m @ 1300 rpm |
| Fuel Consumption @ Rated Power | 227g/Kw.h |
| Idel Speed | 800 rpm |
| Max. Continuous Running Altitude | 2000 m |
With warranty for 12 month or 1000 hours, depend on what comes
first.
cummins diesel engine easy to repair, have service site all over
the world, parts supply from
every local engine service site.
Packaging & Delivery
Packaging Detail:
Packaged By Exporting plywood case,woooden.
Delivery Detail:
Shipped in 3-10 working days after yr advance payment
We can provide ORIGINAL CUMMINS engines used for Industry, Bus,
Marine, Generator Set and water pump. More details, please contact
us via email and call. Thanks !
Engine For Construction Machinery Photo:
