Description of 250KW/312KVA Generator:
| 1. Specification of genset |
| Gensets model | XS-280 |
| Prime power | 280KW/350KVA |
| Rated Voltage | 400V |
| Rated frequency(HZ) | 50 |
| Rated Speed | 1500rpm |
| Dimensions(mm) (L×W×H) | 3120*1200*1620 | open type |
| Genset Weight(kg) | 2600 |
|
| 2. Specification of diesel engine |
| Engine brand | MTAA11-G3 |
| Engine model | MTAA11-G3 |
| Number of Cylinders | 6 |
| Cylinder arrangement | L |
| Bore×Stroke (mm×mm) | 140*152 |
| | |
| 3. Specification of alternator |
| Alternator brand | Xiangyang Xinsheng |
| Alternator model | HJI250KW |
| Number of Phase | 3 |
| Connecting Type | 3 Phase and 4 Wires |
| Protection Grade | IP23 |
| Altitude | ≤1000m |
Engine Feature for generator 350kva manufacturer
1.Diesel, heavy-duty, four stroke, water cooled and direct
injection fuel system
2.24/12V D.C starter and charger alternator
3.Industrial capacity exhaust silencer supplied loose with flexible
section
4.Engine driven cooling fan with protection guard
5.Steel wire braided fuel lines, vent and rain fittings
6.Set mounted acid battery installed with leads and terminals
Alternator Feature for generator 350kva manufacturer
1.Brushless self excited, single bearing, 4 poles
2.Class H insulation
3.IP21/23 protection standard
4.Self-exciting and self-regulating
5.Automatic voltage regulator (AVR)
Control System for generator 350kva manufacturer
1.manual / auto start and protection module
2.Equipped with Deep Sea,ComAp,Harsen,Smartgen famous control systems.
3.New integrated controllers in manual and remote start application.
4.Featuring full gen-set monitoring and protection.
5.Powerful graphic display, Icons, symbols and bar graphs
6. High functionality set new standards in gen-set control.
Our Warehouse:
A: Test before shippment
- Each Generator Set shall be put into commission more than 4 hours
totally, tested on idle load, fully load and 10% overload.
- Noise level shall be tested.
- All of the meters on the control panel shall be tested.
- The appearance of the Set and the label, nameplate shall be
tested. "
-Voltage available: 50Hz: 380-400-415V/ 220-230-240V; 60Hz:
220-380-416-440-480V/ 110-208-220-
240V. Any special voltage is also available as cilent's request.
B: Packing & Warranty
- Packing: Wooden Case, Plywood or Metal Case.
- Delivery Time: Less than 25 working days after receiving
prepayment.
- Warranty: One year or 1, 000 hours from the date of shippment
(15 Months or 1, 200 hours for Alternator Part).
