8.9L 4 Cylinder Diesel Truck Engines C245-33 Assembly ISO14001
Certification
Features and benefits:
1. Six-cylinder, water-cooled, in-line diesel engine.
2. 12 months after-sale service.
3. After-sale service all over the world.
4. Direct injection internal combustion engine.
5. Efficient fuel system for max power output and durability.
Specifications:
| Cummins C245-33 Truck Engine |
| Engine model | C245-33 |
| Engine series | Dongfeng Cummins C8.3 Series |
| Engine manufacturer | Dongfeng Cummins Engine Co., Ltd |
| Suitable for | Truck |
| Air intake ways | Turbo charged, air-to-air cooled |
| Cylinder number | 6 |
| Fuel type | Diesel |
| Engine cylinders position | 6 cylinders in line |
| Displacement | 8.3L |
| Emission level | Euro 3 |
| Max output power | 180kw |
| Rated power speed | 2200RPM |
| Max horse power | 245HP |
| Max torque | 1025N.m |
| Max torque speed | 1400r/min |
Description:
Cummins C Series Engine Advantages:
1. High fuel efficiency.
2. The durability and compact dimensions.
3. The design of dual ni-resist pistons and greater main bearing
area.
4. Advanced design and manufacturing.
5. Excellent cold start performance.
6. Excellent performance and advantage.
Cummins Truck Engnies Modle List:
Type | Model | Rated power/Speed | PeakTorque/Speed |
(kW/rpm) | (N.m/rpm) |
B(3.9L) | B125 33 | 92/2500 | 410/1500 |
B140 33 | 103/2500 | 502/1500 |
EQB125-20 | 92/2800 | 410/1500 |
EQB140-20 | 103/2700 | 502/1500 |
B(5.9L) | B160 33 | 118/2500 | 500/1400 |
B170 33 | 125/2500 | 560/1300 |
B180 33 | 132/2500 | 610/1500 |
B190 33 | 140/2500 | 640/1500 |
B210 33 | 155/2500 | 700/1500 |
EQB160-20 | 118/2600 | 550/1500-1700 |
EQB160-20 | 118/2600 | 570/1400-1600 |
EQB170-20 | 125/2500 | 570/1400-1600 |
EQB170-21 | 125/2500 | 560/1300 |
EQB180-20 | 134/2500 | 624/1400 |
EQB180-20 | 134/2500 | 610/1400-1600 |
EQB180-20 | 132/2500 | 610/1600 |
EQB190-21 | 140/2500 | 640/1300-1500 |
EQB210-20 | 155/2500 | 700/1400-1600 |
EQB210-20 | 155/2500 | 700/1500 |
C(8.3L) | C230 33 | 170/2200 | 861/1300 |
C245 33 | 180/2200 | 1025/1400 |
C260 33 | 191/2200 | 1025/1400 |
C280 33 | 206/2200 | 1125/1200 |
C300 33 | 221/2200 | 1125/1500 |
C220 20 | 162/2200 | 800/1400 |
C230 20 | 169/2200 | 830/1400 |
C230 20 | 170/2200 | 830/1400 |
C245 20 | 180/2200 | 1025/1400 |
C245 20 | 181/2200 | 1040/1400 |
C260 20 | 191/2200 | 1025/1400 |
C260 20 | 191/2200 | 1025/1300 |
C260 20 | 191/2200 | 1025/1400-1500 |
C280 20 | 206/2200 | 1125/1400 |
C300 20 | 221/2200 | 1125/1200-1400 |
C300 20 | 221/2200 | 1125/1300 |
L(8.9L) | L270 30 | 199/2200 | 1150/1400 |
L290 30 | 213/2200 | 1200/1300 |
L315 30 | 231/2200 | 1180/1300 |
L340 30 | 250/2200 | 1350/1400 |
L360 30 | 265/2200 | 1480/1400 |
L375 30 | 276/2200 | 1480/1400 |
L280 20 | 206/2200 | 1150/1400 |
L300 20 | 221/2200 | 1180/1400 |
L300 20 | 221/2200 | 1200/1400 |
L325 20 | 239/2200 | 1230/1300 |
L325 20 | 239/2200 | 1230/1400 |
L340 20 | 250/2200 | 1350/1400 |
L360 20 | 264/2200 | 1480/1300 |
Applications:
Cummins truck diesel engines are widely used for light truck, light
truck and many kinds refitted vehicles, such as garbage trucks,
sweeper, dump trucks.
Packaging & Delivery
Packaging Details:
1. Packed in wooden case, 1 unit/wooden case.
2. Packing sieze: 1300*900*1300mm
Delivery Detail:
2-3 days for 1-10 units; 7-10 days for 10-20 units.
Our Service:
1. 100% finished products inspection before shipment. Beside
customer's QC, we can help to do inspection and offer report.
2. We can palletize, make fumigation, supervise over loading, take
loading photos for customers.
3. Offer CO, Form A, Form E, Form F and certificate legalized by
concerned embassy.
4. One year warranty for after-service.
